AceCrew Electric Solenoid Valve 1/4 inch NPT 220V, 240V AC Normally Open - flow control valve for gas, air & water
$25.98
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by constructioncleanla.com
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here.
$25.98
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by constructioncleanla.com
Free 30-day returns Details
Product details
| Management number | 218102097 | Release Date | 2026/05/03 | List Price | $10.39 | Model Number | 218102097 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- AceCrew Industrial grade Electric Solenoid Valve Normally Open
- Size 1/4 inch NPT thread ,Voltage AC 220V, 240V
- Brass inlet & outlet NPT Thread , easy to install with 2-way 2-position direct lift diaphragm
- Normally Open operation for gas and liquid flow control. Valve will close when energized. Suitable for operation systems that requires constant flow of fluid, gas & water in irrigation , gas activated and automated equipment , HVAC systems Flow rate Cv = 0.5 ; Unidirectional (indication on brass body)
- Pipe Size : 1/4" NPT Female (18 TPI) . Orifice Diameter : 5/32" (4 mm) Seal/Diaphragm : NBR (Buna-N, Perbunan, and Nitrile rubber)
- Current : 0.1 Amp . Wattage : 24 Watt. Operating Pressure Differential : 0-145 psi (0-1 MPa, gravity-feed capable)
- Suitable for Low viscosity fluid, Water, air, natural gas, propane, butane, petroleum oil, mineral oils, diesel. Not Suitable for gasoline.
- Operating Temperature : 15-125 °F (-10~50 °C).To avoid damaging the coil , this valve is not recommended to be in continuous use for more than 8 hours in a single cycle. Media Temperature : 15-180 °F (-10~80 °C).
- Weight of solenoid valve : 14 oz One Year Warranty
| UPC | 610877609680 |
|---|---|
| Size | 1/4 inch |
| Set Name | AceCrew |
| Brand Name | Ace Crew |
| Unit Count | 1.0 Count |
| Valve Type | Diaphragm Valve Solenoid Normally Open 1/4 inch 220V, 240V AC |
| Thread Size | 1/4 inch |
| Thread Type | NPT |
| Manufacturer | AceCrew |
| Model Number | Normally Open 1/4 inch , 220V - 240V AC |
| Material Type | Brass port, Coil : Copper wire in resin-molded casing, Seal/Diaphragm : NBR (aka Buna-N, Perbunan, and nitrile rubber) |
| Connector Type | DIN |
| Item Type Name | Normally Open Electric Solenoid Valve 1/4 Inch 220V, 240V AC |
| Exterior Finish | Brass |
| Number of Ports | 2 |
| Maximum Pressure | 145 Pound per Square Inch |
| Number of Pieces | 1 |
| Specification Met | DIN, NBR, NPTS |
| Included Components | Brass NPT thread body 1/4 Inch Normally Open, Electromagnetic Coil Solenoid 220V, 240VAC |
| Inlet Connection Size | 0.25 Inches |
| Inlet Connection Type | FNPT |
| Outlet Connection Size | 0.25 Inches |
| Outlet Connection Type | FNPT |
| Manufacturer Part Number | NO 1/4" 220VAC |
